DC-DC Step-up/step-down konvertor 5-30V/1.25-30V 6A

Opis

- Module Type: BUCK,

- Input Voltage: 5-30V (Max.30V),

- Output Voltage: 1.25-30V adjustable (Default 5V),

- Output Current: Max 12A (Rated 8A, Max. 12A 100W, 200W with enhanced cooling),

- Working Temperature: -40.0 - 85.0 °C,

- Working Frequency: 300KHz,

- Short Circuit Protection: Yes (12A Limited),

- Over Temperature Protection: Yes,

- Reverse Input Protection: No (Connect diode if necessary),

- Installation: 4 x 3mm screws,

- Wiring: Connect wire terminals, no need soldering, V-IN as input, V-OUT as output,

- Module Size: Approx. 60 x 51 x 22/2.36 x 2.01 x 0.87 inch.
