Rele FRT5-DC12V

Opis

Relay DPDT 1A 12V 1028R, made by Forward Industries. Small size and ultra slim (only 5mm). Single side stable. Low coil power consumption of 140mW. Wash tight construction RTIII (IP67). PCB mounting or insertable in a DIP/DIL socket.

- Switching: DPDT,

- Contact Material: AgPd / AgPdAu,

- Contact Rating: 1A / 30V DC 0,5A / 125V AC,

- Rated Current: 1A,

- Max. Switching Current: 1A,

- Max. Switching Voltage: 250V AC / 220V DC,

- Max. Switching Power: 30W / 62,5VA,

- Operate/Release Time; Max.: 2/1ms,

- Testing Voltage (FCC) Coil/Contact: 1500V AC,

- Contact/Contact: 1500V AC,

- Lifetime Electrical (1A/30V DC): 2x10'5 Operations,

- Mechanical: 1x10'8 Operations,

- Operating Temperature: -40...+70'C,

- Weight approx.: 1,5g.
